Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Contact Form | SPDT |
| Current Rating | 8 A |
| Function | Multi-Function |
| Mounting Type | DIN Rail |
| Relay Type | Mechanical Relay |
| Series | |
| Termination | Screws |
| Timing Range | 0.1 Sec. to 100 Hrs. |
| Voltage, Control | 24-240 VAC ; 24 VDC |
| Voltage, Switching | 8A @ 250VAC |
Overview
Chronos 2 is a new complete range of timers for which several patents have been obtained. Both consistent and innovative in design, it responds to market requirements. For ease of use, all parameters can be set on the front face, using rotary switches to select any of its 10 functions and seven timing ranges. The face also incorporates a display of the preset time and LED status indicators. The products demonstrate our concern for the environment, using green materials throughout — Cadmium-free relay contacts, laser-etched front and side face, avoiding the use of solvents, etc. One LED status indicator, DIN-rail mount and five single function units available. Features:
